Interface

8 10/100/1000Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)
2 1000Mbps SFP Slots 1 Console Port

  Network Media

10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
100BASE-TX/1000Base-T: UTP category 5, 5e, 6 or
above cable (maximum 100m)
1000BASE-X: MMF, SMF
1000Base-L X:62.5μm/50μm MM(2m~550m) or 10μm SMF(2m~5000m)

  Fan Quantity

Quantity Fanless

  Exchange Capacity

20G

  Packet Forwarding Rate

14.9Mpps

  Mac Address Table

8K

  Packet Buffer Memory

4Mb

  Jumbo Frame

10240 Bytes


  Dimensions

Product Size： 225mm*105mm*32mm （L*W*H）

  Quality of Service

Support 802.1p CoS/DSCP priority Support 4 priority queues Queue scheduling: SP, WRR,SP+WRR Port/Flow- based Rate Limiting

  L2 Features

IGMP Snooping V1/V2/V3 802.3ad LACP (Up to 8 aggregation groups, containing 8 ports per group) Spanning Tree Port isolation

  VLAN

Supports up to 4K VLANs simultaneously (out of 4K VLAN IDs) Port/ MAC/Protocol-based VLAN Management VLAN configuration

  Access Control List

L2～L4 package filtering based on source and destination MAC address, IP address, TCP/UDP ports, 802.1p, DSCP, protocol and VLAN ID; Time Range Based

SSH v1/v2 Port Security Broadcast/Multicast/Unknown- unicast Storm Control



  Management

Web-based GUI and CLI management CPU Monitoring Port Mirroring Time Setting: SNTP Integrated NDP/NTDP feature Firmware Upgrade: TFTP & Web

  Certification

CE, FCC, RoHS

  Package Contents

Gigabit Switch Electric Line Guide Book/Warranty Card



  Environment

Working Temperature： -10℃～55℃ Storage temperature ： -40℃～70℃ Working Humidity ： 10%～90% RH non-condensing Storage Humidity： 5%～90% RH non- condensing
