Product code

RDS2216-2XG-4S+4XS-2XQ

  Architecture

ARM 64bit

  CPU

AL73400

  CPU core count

16

  CPU nominal frequency

2000 MHz

  RouterOS license

6

  Operating System

RouterOS 7

  Size of RAM

32 GB

  Storage size

128 MB

  Storage type

NAND

  MTBF

Approximately 200’000 hours at 25C

  Tested ambient temperature

-20°C to 50°C

  Powering

  Number of AC inputs

2

  AC input range

100-240

  Frequency (Hz)

50-60

  Max power consumption

286 W

  Max power consumption without attachments

105 W

  Cooling type

10 fans

  Ethernet

  10/100/1000 Ethernet ports

1

  Number of 1G/2.5G/5G/10G Ethernet ports

2

  Fiber

  SFP+ ports

4

  Number of 25G SFP28 ports

4

  Number of 100G QSFP28 ports

2

  Peripherals

  Serial console port

RJ45

  Number of USB ports

2

  USB Power Reset

Yes

  USB slot type

USB 3.0 type A

  Max USB current (A)

1

  Number of M.2 slots

2

  Certification & Approvals

  Certification

CE, EAC, ROHS

  IP

20

  The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase.
